Description
Single-row deep groove ball bearings, series 6000 (FAG · ECO line). It is the reduced-section series which, for the same bore, has a smaller outer diameter and width than the 6200, useful where space is tight and loads are moderate. This page lists 88 codes, with bores from 10 to 50 mm: choose the code from the menu above.
- TypeSingle-row deep groove ball bearings
- Series6000
- Bore dfrom 10 to 50 mm
- Outer diameter Dfrom 26 to 80 mm
- Codes88
- BrandFAG · ECO line
Features
- They take radial loads and moderate axial loads in both directions
- Low friction and high speeds, quiet running
- ISO standard dimensions: interchangeable between brands
- Open, shielded (ZZ/2Z) or rubber-sealed (2RS) versions lubricated for life
Typical applications
Operating conditions
| Loads | Radial; moderate axial in both directions |
|---|---|
| Speed | High (open versions are the fastest) |
| Misalignment | Poorly tolerated: shaft and housing must be aligned |
| Lubrication | Grease (for life in ZZ and 2RS versions) or oil |
| Temperature | Usually up to about +120 °C; with rubber seals the limit is set by the seal (about +100 °C) |
Advantages
- The most versatile and easiest bearing to find
- Suitable for high speeds
- Low maintenance in shielded or sealed versions
- Low cost
Limitations
- Only moderate axial loads
- Does not compensate for misalignment between shaft and housing
- For very heavy radial loads or shocks, a roller bearing is better
How to read the code
| 2RS | rubber seals on both sides: protection against dust and splashes, lubricated for life |
|---|---|
| ZZ / 2Z | metal shields on both sides: protection against dust, minimal friction, lubricated for life |
| C3 | increased internal radial clearance: for tight fits or high temperatures (typical of electric motors) |
| FAG | Schaeffler FAG brand |
| ECO | economy line alternative to FAG, for less demanding uses |
Available codes
The d × D × B dimensions (bore, outer diameter, width) of each code appear in the "Sizes" menu; variants with a suffix (2RS, ZZ, C3…) are listed in the series menu.
Technician's tipTo replace a bearing, all you need is the code engraved on the outer ring: the first digits indicate type and series, the last two the bore (from 04 upwards, multiplied by 5: 6205 = 25 mm bore). If the old one was 2RS or ZZ, take the same protection.
Temperatures and speeds are general guidelines for standard steel bearings: for special conditions ask us for the manufacturer's data.
Available codes and sizes (88)Click a code to select it on this page.
| Code | Sizes | Price |
|---|---|---|
| 6000-FAG | d-10 D-26 B-8 | 1.71 |
| 6000-2RS-FAG | d-10 D-26 B-8 | 2.22 |
| 6000-2RS-C3-FAG | d-10 D-26 B-8 | 2.22 |
| 6000-2RS-ECO | d-10 D-26 B-8 | 0.51 |
| 6000-2Z-FAG | d-10 D-26 B-8 | 1.95 |
| 6000-2Z-C3-FAG | d-10 D-26 B-8 | 1.95 |
| 6000-2Z-ECO | d-10 D-26 B-8 | 0.51 |
| 6000-C3-FAG | d-10 D-26 B-8 | 1.71 |
| 6001-FAG | d-12 D-28 B-8 | 1.82 |
| 6001-2RS-FAG | d-12 D-28 B-8 | 2.38 |
| 6001-2RS-C3-FAG | d-12 D-28 B-8 | 2.38 |
| 6001-2RS-ECO | d-12 D-28 B-8 | 0.59 |
| 6001-2Z-FAG | d-12 D-28 B-8 | 2.11 |
| 6001-2Z-C3-FAG | d-12 D-28 B-8 | 2.11 |
| 6001-2Z-ECO | d-12 D-28 B-8 | 0.59 |
| 6001-C3-FAG | d-12 D-28 B-8 | 1.71 |
| 6002-FAG | d-15 D-32 B-9 | 2.00 |
| 6002-2RS-FAG | d-15 D-32 B-9 | 2.61 |
| 6002-2RS-C3-FAG | d-15 D-32 B-9 | 2.61 |
| 6002-2RS-ECO | d-15 D-32 B-9 | 0.63 |
| 6002-2Z-FAG | d-15 D-32 B-9 | 2.31 |
| 6002-2Z-C3-FAG | d-15 D-32 B-9 | 2.31 |
| 6002-2Z-ECO | d-15 D-32 B-9 | 0.63 |
| 6002-C3-FAG | d-15 D-32 B-9 | 2.00 |
| 6003-FAG | d-17 D-35 B-10 | 2.11 |
| 6003-2RS-FAG | d-17 D-35 B-10 | 2.75 |
| 6003-2RS-C3-FAG | d-17 D-35 B-10 | 2.75 |
| 6003-2RS-ECO | d-17 D-35 B-10 | 0.74 |
| 6003-2Z-FAG | d-17 D-35 B-10 | 2.44 |
| 6003-2Z-C3-FAG | d-17 D-35 B-10 | 2.44 |
| 6003-2Z-ECO | d-17 D-35 B-10 | 0.74 |
| 6003-C3-FAG | d-17 D-35 B-10 | 2.11 |
| 6004-FAG | d-20 D-42 B-12 | 2.34 |
| 6004-2RS-FAG | d-20 D-42 B-12 | 3.05 |
| 6004-2RS-C3-FAG | d-20 D-42 B-12 | 3.05 |
| 6004-2RS-ECO | d-20 D-42 B-12 | 0.99 |
| 6004-2Z-FAG | d-20 D-42 B-12 | 2.70 |
| 6004-2Z-C3-FAG | d-20 D-42 B-12 | 2.70 |
| 6004-2Z-ECO | d-20 D-42 B-12 | 0.99 |
| 6004-C3-FAG | d-20 D-42 B-12 | 2.34 |
| 6005-FAG | d-25 D-47 B-12 | 2.68 |
| 6005-2RS-FAG | d-25 D-47 B-12 | 3.50 |
| 6005-2RS-C3-FAG | d-25 D-47 B-12 | 3.50 |
| 6005-2RS-ECO | d-25 D-47 B-12 | 1.24 |
| 6005-2Z-FAG | d-25 D-47 B-12 | 3.09 |
| 6005-2Z-C3-FAG | d-25 D-47 B-12 | 3.09 |
| 6005-2Z-ECO | d-25 D-47 B-12 | 1.24 |
| 6005-C3-FAG | d-25 D-47 B-12 | 2.68 |
| 6006-FAG | d-30 D-55 B-13 | 3.31 |
| 6006-2RS-FAG | d-30 D-55 B-13 | 4.28 |
| 6006-2RS-C3-FAG | d-30 D-55 B-13 | 4.28 |
| 6006-2RS-ECO | d-30 D-55 B-13 | 1.46 |
| 6006-2Z-FAG | d-30 D-55 B-13 | 3.79 |
| 6006-2Z-C3-FAG | d-30 D-55 B-13 | 3.79 |
| 6006-2Z-ECO | d-30 D-55 B-13 | 1.46 |
| 6006-C3-FAG | d-30 D-55 B-13 | 3.31 |
| 6007-FAG | d-35 D-62 B-14 | 4.09 |
| 6007-2RS-FAG | d-35 D-62 B-14 | 5.31 |
| 6007-2RS-C3-FAG | d-35 D-62 B-14 | 5.31 |
| 6007-2RS-ECO | d-35 D-62 B-14 | 1.94 |
| 6007-2Z-FAG | d-35 D-62 B-14 | 4.70 |
| 6007-2Z-C3-FAG | d-35 D-62 B-14 | 4.70 |
| 6007-2Z-ECO | d-35 D-62 B-14 | 1.94 |
| 6007-C3-FAG | d-35 D-62 B-14 | 4.09 |
| 6008-FAG | d-40 D-68 B-15 | 5.12 |
| 6008-2RS-FAG | d-40 D-68 B-15 | 6.69 |
| 6008-2RS-C3-FAG | d-40 D-68 B-15 | 6.69 |
| 6008-2RS-ECO | d-40 D-68 B-15 | 2.21 |
| 6008-2Z-FAG | d-40 D-68 B-15 | 5.92 |
| 6008-2Z-C3-FAG | d-40 D-68 B-15 | 5.92 |
| 6008-2Z-ECO | d-40 D-68 B-15 | 2.21 |
| 6008-C3-FAG | d-40 D-68 B-15 | 5.12 |
| 6009-FAG | d-45 D-75 B-16 | 6.71 |
| 6009-2RS-FAG | d-45 D-75 B-16 | 8.78 |
| 6009-2RS-C3-FAG | d-45 D-75 B-16 | 8.78 |
| 6009-2RS-ECO | d-45 D-75 B-16 | 4.39 |
| 6009-2Z-FAG | d-45 D-75 B-16 | 7.69 |
| 6009-2Z-C3-FAG | d-45 D-75 B-16 | 7.69 |
| 6009-2Z-ECO | d-45 D-75 B-16 | 3.90 |
| 6009-C3-FAG | d-45 D-75 B-16 | 6.71 |
| 6010-FAG | d-50 D-80 B-16 | 7.81 |
| 6010-2RS-FAG | d-50 D-80 B-16 | 10.13 |
| 6010-2RS-C3-FAG | d-50 D-80 B-16 | 10.13 |
| 6010-2RS-ECO | d-50 D-80 B-16 | 5.12 |
| 6010-2Z-FAG | d-50 D-80 B-16 | 8.91 |
| 6010-2Z-C3-FAG | d-50 D-80 B-16 | 8.91 |
| 6010-2Z-ECO | d-50 D-80 B-16 | 4.51 |
| 6010-C3-FAG | d-50 D-80 B-16 | 7.81 |
Equivalent designations across brands: 2RS (rubber seals on both sides) = 2RSR FAG = 2RS1 / 2RSH SKF = DDU NSK = LLU NTN; 2Z (metal shields on both sides) = 2ZR FAG = 2Z SKF = ZZ NSK, NTN and Koyo; C3 = increased radial internal clearance, the same for all brands.
